Describe any robot in plain English. Get a complete design package you can build.

The package holds the mechanical CAD, the electronics and PCB, the firmware and simulation, and a priced bill of materials.

Request a pilotSee an example
Every part of the example's design laid out as a kit on an engineering grid: tubes, plates, brackets, six motors and propellers, the board, and the specification's tiles.
The example below, finished: every part of the drone's design laid out as a kit, with its board and the numbers of its specification.

Example: an agricultural mapping drone

One paragraph in, a design package out, in five steps.

  1. Step 1 of 5

    You describe the robot you need.

    In plain English. One paragraph is enough.

    The description:

    A hexacopter agricultural mapping drone carrying a multispectral camera, 3 kg payload, brushless motors, GPS and IMU, 12 S LiPo, PA12 and carbon-fibre, flies over fields to survey crop health. Medium volume. BOM under 6000 USD.
  2. Engraved tiles on a grid reading 3 kg payload, 30 min endurance, 16.8 kg take-off mass, 6 rotors and 44.4 V battery.

    Step 2 of 5

    Anubis turns it into an engineering specification.

    payload 3 kg · endurance 30 min · take-off mass 16.8 kg · rotors 6 · battery 44.4 V · wind 8.9 m/s

  3. The design's parts laid out in rows: carbon tubes, plates, brackets, propellers and a small green circuit board.

    Step 3 of 5

    It designs every part.

    21 part designs: the made parts, and the bought parts from their makers' own CAD · 99 pieces · CFRP · PA12 · aluminium

  4. Two sheets standing on the grid: the copper of the board's layout and the priced bill of materials.

    Step 4 of 5

    It produces the documents.

    the board, 4 copper layers · a priced bill of materials, 16 lines shown

  5. The run's own isometric render of the assembled hexacopter: six arms with motors and propellers around a central body with the payload underneath.

    Step 5 of 5

    Ready to build.

    The assembled drone, rendered from the design's own model.

The whole package, from one paragraph. Yours next.

Design runs are invite-only during the pilot

Tell us about the robot you need and we run Anubis on it with you. Or open this example, Agricultural mapping hexacopter, in the workspace: every tab, every gate result and the evidence behind it, read-only.

Request a pilotOpen the example: Agricultural mapping hexacopter
